iMarquee: Zero PLC Logic Change LED Message Board™

PLC LED Message Board — "Zero Change Required to PLC Logic" to Implement Message Display

Add plant-floor messages, alarms, and production status without changing existing PLC code.

$2,069 for 2 Line 20 Char. Tri-color
Read PLC data directly
No PLC code change required
See how it works
 Product
Overview Review
Specifications Check
Dimensions Compare to
InView See
Videos
led message display with tri color reading

Configure and Add to Cart

OR

Email Sample Message &
We'll Configure for You!

30-Second Comparison to InView

Spectrum Controls
2706-P42C2-SC - $5788 + 2706-PENETI-SS Ethernet Module - $992 = $6780
(Slave Marquee, requires PLC to send ASCII strings)
EZAutomation EZiMT-2L20C - $2069
(Master Marquee that reads PLC tags, No change in PLC logic required)
Brightness / Intensity
1200 NITS
Brightness / Intensity
4000 NITS
Power Consumption
110-250 VAC, 84 W.
Power Consumption
110-250 VAC, 55 W. 1/2 of Spectrum
Weight
11.4 lb.
Weight
5.2 lb.
Full Brightness Operating Temperature
Dims to 50% brightness at 30°C ambient and complete shutdown at 40°C
Full Brightness Operating Temperature
Full brightness to 60° C.
Character Set
English Only
Character Set
International
Connectivity
Limited only to Rockwell or Modbus
Connectivity
RS232, 422, 485, EthernetIP, Modbus TCP/IP, GE SRTP, Siemens ISO, Devicenet, Profibus, and DH+
Wi-Fi Module
Not available
Wi-Fi Module
$206 Program without connecting cable from marquee to laptop
Risk
Frequent obsolescence P22, 42, 44, 72, 74 already declared obsolete
NO RISK
No obsolescence, Made in America, available in stainless steel also and talks to all Industrial networks like DH+, RIO, Devicenet, Profibus, CC Link, Modbus Plus. All Ethernet and Serial PLC drivers available.

Most plants recognize the value of a Marquee, but hesitate for fear of disturbing PLC logic.

iMarquee Eliminates that Risk

Ordinary LED message boards

  • Require PLC programming or ladder changes.
  • Create fear of disturbing a running machine.
  • Need engineering time for simple plant messages.

EZ iMarquee

  • Reads the PLC register or tags directly.
  • Displays pre-programmed messages from the marquee while incorporating the variable data from the PLC tags.
  • Leaves signed-off and working PLC code alone.

How the iMarquee works

The PLC continues doing what it already does. The iMarquee watches selected PLC tags and displays the right message when the condition appears.

1

Connect to PLC

Use the industrial communication driver to read the selected PLC tags.

2

Load messages

Program the message list in the marquee, not inside the PLC logic.

3

Display events

Show alarms, status, counts, faults, or instructions on the plant floor.

How does an EZAutomation marquee pay for itself in <3 months

  • Increases machine/cell/line productivity as production results are clearly visible real time that fosters human competitiveness.
  • It cuts down Maintenance and downtime as the maintenance personnel can see the machine/process issue from 100 ft to 400 ft away.
  • Provides enhanced visibility from a distance.
  • Environmentally and mechanically tough construction of the marquee makes it forklift proof as compoared to digital white boards
  • Increases safety and compliance.
  • You can consider EZMaruqee to be an intelligent digital stack light
LED message displays showing differnt values for production line
ezmarquee hit by foklift in a plant floor but still displaying message

Mechanically Strong Forklift Proof

A fork lift can run into it and it will continue to do its job. If at all some portion of the Marquee is damaged, it can be repaired. On the other hand, a digital white board if damaged, in any way requires full replacement.

message displayed on digital white board

Digital white boards/computer screens not so rugged for plant floors

One avoided failure event can pay for the system.

When operators can see the fault, location, and instruction from across the floor, response time improves. The value is not the LED display. The value is faster action.

Alarms
Line status
Production count
Operator instructions

$2,069 - 2 Line 20 Character Tri-Color iMarquee that connects to all Ethernet protocol.


Add to Cart

Low-risk first install, 30 day money back gurantee.

Ideal for proving the concept on one line before rolling out plant-wide.
